Specifications

  • Frequency Response
  • 13Hz – 35kHz
  • Cantilever
  • Aluminum Pipe
  • Channel Balance
  • <1dB @ 1kHz
  • Channel Separation
  • 30dB @ 1kHz
  • Coils
  • High-Purity Copper
  • Compliance
  • 12×10-6cm/dyn @ 100Hz
  • Internal Impedance
  • 28Ω
  • Load Impedance
  • >100Ω
  • Output
  • 0.5mV @ 1kHz
  • Recommended Tracking Force
  • 2.0g
  • Replacement Stylus Unit
  • Re-Tip Exchange (Contact us)
  • Stylus
  • 0.3 x 0.7mil Elliptical
  • Tracking Force Range
  • 1.8g – 2.2g
  • Vertical Tracking Angle
  • 20°
  • Capacitance (MM Only)
  • 100pF – 200pF
  • Weight
  • 6 kg
  • Height
  • 17.16 mm
  • Width
  • 17.32 mm
  • Length
  • 23.94 mm
