Specifications

  • Frequency Response
  • 10Hz – 50kHz
  • Cantilever
  • ⌀0.28mm Boron Shaft
  • Channel Balance
  • 0.5dB @ 1kHz
  • Channel Separation
  • 30dB @ 1kHz
  • Coils
  • High-Purity Copper
  • Compliance
  • 12×10-6cm/dyn @ 100Hz
  • Internal Impedance
  • 35Ω
  • Load Impedance
  • 100 – 1kΩ
  • Output
  • 0.5mV
  • Recommended Tracking Force
  • 2.0g
  • Replacement Stylus Unit
  • Re-Tip Exchange (Contact us)
  • Stylus
  • Solid Ultra Low-Mass 75µm x 2.5µm Microridge
  • Tracking Force Range
  • 1.9g – 2.2g
  • Vertical Tracking Angle
  • 20°
  • Capacitance (MM Only)
  • 100pF – 200pF
  • Weight
  • 7 kg
  • Height
  • 17 mm
  • Width
  • 18 mm
  • Length
  • 31 mm
