Specifications

  • Color
  •   Red Violin
  • Frequency Response
  • 16 to 30/80Hz -variable based on the setting of the electronic crossover
  • Suggested Amplifier Power Output
  • 100 W–700 W
  • System
  • 4.5-way sealed box
  • Nominal Impedance
  • 4 Ohm
  • Crossover
  • 360Hz,430Hz,1,700Hz,6,700Hz
  • Sensitivity
  • 92 dB 1m/2.83V
  • Drivers
  • MAIN COLUMN: Stw: Ø 20 mm, silk dome with dedicated waveguide, High Power Neodymium, Extended Range Double Soft Dome. Tw: Ø 38 mm, silk dome with dedicated waveguide, High Power Neodymium, Extended Range Double Soft Dome. Md: Ø 165 mm, dual driver motor system with neodymium ring magnet. Lmw: Ø 203 mm, neodymium slug magnet, Ø 65mm voice coil, sandwich paper cone. W: Ø 4x203 mm, dual driver motor system with neodymium ring magnet, Ø 50 mm voice coil, sandwich paper cone, Btw: Ø 28 mm, silk dome, neodymium magnet, Bmd:Ø 101 mm, paper cone driver, neodymium magnet. SUBWOOFER: Ø 2x380 mm carbon fiber sandwich cone
  • Connectivity
  • MAIN COLUMN: 4 connectors binding post: Mid-Hi, Low. SUBWOOFER: 2 connectors binding post, CROSSOVER: INPUT CHANNELS: 2 Unbalanced, 2 Balanced, OUTPUT CHANNELS: 8 Unbalanced, 8 Balanced
