Specifications

  • Color
  •   White
  • Drivers
  • Low frequency drivers: 4 x nominal 130mm (5”) coated paper cones. 26mm (1”) voice coil wound on high powered aluminium former provides enhanced linearity. Over-sized magnet delivers low distortion, Mid frequency driver: 1 x nominal 130mm (5”) coated paper cone. 26mm (1”) voice coil wound on high powered aluminum former, using copper shorting ring and oversized magnet for low distortion, High frequency driver: 26mm (1″) dual concentric diaphragm with wave-guide centre plug for controlled directivity. Non-reflective dual chambered magnet structure with copper shorting ring to lower distortion
  • Power Handling
  • 50 – 300 Watts RMS recommended amplifier power
  • Sensitivity
  • 90dB for 2.83 volts at 1 metre
  • System
  • 3-way
  • Input
  • Input terminals: Gold plated spring terminals
  • Frequency Range
  • 40Hz-40kHz in room response
  • Impedance
  • Nominally 6 Ohms (minimum 4.3 Ohms)
