Specifications

  • Total Harmonic Distortion (THD)
  • Preamplifier: 0.03%, Amplifier: 0.005%
  • Frequency Response
  • +0,-0.5dB: 20Hz to 20kHz, +0, -3dB: 10Hz to 100kHz
  • Sensitivity
  • Sensitivity Phono (Moving Coil): 0.30mV, Sensitivity Phono (Moving Magnet): 3.0mV, Sensitivity High Level (Balanced / Unbalanced): 600 mV/300mV, Sensitivity (Power Amp input): 1.7V
  • DAC
  • 8-channel, 32-bit/384kHz PCM/DSD, Quad Balanced
  • Damping Factor
  • >40
  • Dynamic Headroom
  • 1.5dB
  • Number Of Channels
  • 2
  • Vacuum tube or Solid State
  • Preamplifier: Vacuum Tube, Amplifier: Solid State
  • Signal to noise ratio
  • Signal To Noise Ratio (Moving Coil): 75dB, Signal To Noise Ratio (Moving Magnet): 77dB, Signal To Noise Ratio (High Level): 95dB, Signal To Noise Ratio (Power Amp input): 114dB
  • Input Impedance
  • 44K/22K
  • Connectivity
  • Balanced Input: 2, Unbalanced Input: 6, Phono Input Moving Coil: 1 (adjustable loading), Phono Input Moving Magnet: 1 (adjustable loading), Upgradeable Digital Audio Module: Yes(DA2), Digital Coaxial Input: 2, Digital Optical Input: 2, Digital MCT Input: 1, Digital USB Input: 1, HDMI (ARC) Input: 1, Balanced Variable Output: 1, Unbalanced Fixed Output: 1, Unbalanced Variable Output: 1, Headphone Output: 1/4" High Drive with Headphone Crossfeed Director (HXD®), Home Theater PassThru: Yes, Unbalanced Analog Connector Type: Premium gold-plated solid brass, Speaker Binding Post Type: Patented Solid Cinch™ Speaker Binding Posts, Service Port: 1
