Specifications

  • Audio Inputs
  • 8 x XLR analog inputs
  • Type
  • 8-channel power amplifier
  • Frequency Response
  • ±0.1dB (ref. 20Hz-20kHz)
  • Power Handling
  • 8 x 400 W @4Ω (2-CHANNEL mode), 8 x 200 W @8Ω (2-CHANNEL mode), 4 x 800 W @8Ω (BRIDGE mode)
  • Damping Factor
  • >1200 (8 Ω, 20Hz-1kHz)
  • Max output current per channel
  • 25A
  • Total Harmonic Distortion
  • 0.001% @200 W, 8 Ohm / 340 W, 4 Ohm, 20Hz-20kHz, 0.0006% @10 W, 4 Ohm, 20Hz-20,000Hz, LOW Sensitivity mode, 0.0007% @10 W, 4 Ohm, 20Hz-20,000Hz, HIGH Sensitivity mode
  • Signal to noise ratio
  • 128dB (A-weighted ref. rated power, LOW Sensitivity mode)
  • Audio Outputs
  • 8 x Neutrik speakON
  • Gain
  • HIGH Sensitivity mode: 26.1 dB (2-CHANNEL mode), 31.7 dB (BRIDGE mode), LOW Sensitivity mode: 16.6 dB (2-CHANNEL mode) 22.2 dB (BRIDGE mode)
  • Input Sensitivity
  • HIGH Sensitivity mode: 2V, LOW Sensitivity mode: 6V
  • Power Consumption
  • Idle power consumption: 29 W, Standby power consumption: <0.5W
  • Max output voltage per channel
  • 58V peak (2-CHANNEL mode), 116V peak (BRIDGE mode))
  • Weight
  • 10.3 kg
  • Height
  • 145 mm
  • Width
  • 450 mm
  • Length
  • 349 mm
