Specifications

  • Color
  •   Red
  • Type
  • Passive
  • Drivers
  • Tw: Ø 28 mm, H28 XTR-04, High Power Neodymium, Extended Range Soft Dome, DAD™ Arrow Point. Md: Ø 180 mm, M18 XTR-04 Neodymium Magnet System, W: Ø 2x220 mm W22XTR-12, Sw: Ø 320 mm SW32XTR-08.
  • Suggested Amplifier Power Output
  • 100-1000 W
  • Frequency Response
  • 18 Hz – 35000 Hz
  • System
  • 3 and 2/3 way, Sound field Shaper technology, Zero Vibration Transmission™ technology, para-aperiodic vented box “Stealth Ultraflex System™” and staggered low frequency floor standing loudspeaker system
  • Nominal Impedance
  • 4 Ohm
  • Crossover
  • 55, 150, 200, 3000 Hz Premium High-End components
  • Sensitivity
  • 92 db SPL (2.83 V/1 m)
  • Connectivity
  • 6 connectors binding post: Mid-Hi, Low, Sub
  • Weight
  • 165 kg
  • Height
  • 1725 mm
  • Width
  • 482 mm
  • Length
  • 780 mm
Product Files
Owners manual
