INT203

WEISS Engineering



THE INT203



The INT203 is for bidirectional interfacing between AES/EBU and Firewire and also includes an infrared remote control for volume and absolute polarity.

The bit transparency of the player software on the computer can be checked. The INT203 can serve as an input to the computer, e.g. to connect an A/D Converter for transferring vinyl records or other analog media.

SYNCHRONIZATION



The sampling frequency is generated with an internal generator in the INT203. This ensures a low-jitter transfer between the computer and D/A converter. In addition, the INT203 can be switched to external synchronization via its XLR or RCA AES/EBU inputs. Both units work at all standard sampling frequencies between 44.1 and 192 kHz.

Device supports bit transparency checking. In addition, there is a digital level control with a proper dithering algorithm applied.

Availability: Upon Order.
€1,050.00
INTERESTED IN PRODUCT

Specifications

  • Digital Inputs
  • Two Firewire 400 connectors (also serve as output with the INT203), RCA connector (INT203 only), XLR connector (INT203 only).
  • Outputs
  • One RCA connectors, One XLR connectors, Word-length up to 24 bits.
  • Synchronization
  • Sampling frequency is generated internally, INT203: Synchronization can be supplied via the RCA or XLR inputs, Supported sampling frequencies: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, and 192 kHz.
  • Height
  • 44.4 mm
  • Width
  • 105 mm
  • Length
  • 105 mm
